簡介

mysqld_exporter是用于獲取mysql實例的指標服務。

安裝

運維監控系統之Prometheus-MySQL監控

mysql授權

CREATE USER exporter@localhost identified by "mima";

GRANT PROCESS, REPLICATION CLIENT, SELECT ON *.* TO 'exporter'@'localhost' WITH MAX_USER_CONNECTIONS 3;

flush privileges;

直接通過命令下載就可以了。

wget -t 1000 -c https://github.com/prometheus/mysqld_exporter/releases/download/v0.12.1/mysqld_exporter-0.12.1.linux-amd64.tar.gz

tar zxvf mysqld_exporter-0.12.1.linux-amd64.tar.gz -C /opt/

cd /opt/mysqld_exporter-0.12.1.linux-amd64

export DATA_SOURCE_NAME='exporter:mima@(localhost:3306)/'

./mysqld_exporter

這里設置用戶名密碼是通過環境變量的形式，也可以用配置文件，默認找的配置文件是~/.my.cnf，也可以使用參數--config.my-cnf="/opt/mysqld_exporter/.my.cnf" 進行設置。

./mysqld_exporter --config.my-cnf="/opt/mysqld_exporter/.my.cnf"

其他參數

usage: mysqld_exporter [<flags>]

Flags:

  -h, --help                   Show context-sensitive help (also try --help-long and --help-man).

      --exporter.lock_wait_timeout=2

                               Set a lock_wait_timeout on the connection to avoid long metadata locking.

      --exporter.log_slow_filter

                               Add a log_slow_filter to avoid slow query logging of scrapes. NOTE: Not supported by Oracle MySQL.

      --collect.heartbeat.database="heartbeat"

                               Database from where to collect heartbeat data

      --collect.heartbeat.table="heartbeat"

                               Table from where to collect heartbeat data

      --collect.info_schema.processlist.min_time=0

                               Minimum time a thread must be in each state to be counted

      --collect.info_schema.processlist.processes_by_user

                               Enable collecting the number of processes by user

      --collect.info_schema.processlist.processes_by_host

                               Enable collecting the number of processes by host

      --collect.info_schema.tables.databases="*"

                               The list of databases to collect table stats for, or '*' for all

      --collect.mysql.user.privileges

                               Enable collecting user privileges from mysql.user

      --collect.perf_schema.eventsstatements.limit=250

                               Limit the number of events statements digests by response time

      --collect.perf_schema.eventsstatements.timelimit=86400

                               Limit how old the 'last_seen' events statements can be, in seconds

      --collect.perf_schema.eventsstatements.digest_text_limit=120

                               Maximum length of the normalized statement text

      --collect.perf_schema.file_instances.filter=".*"

                               RegEx file_name filter for performance_schema.file_summary_by_instance

      --collect.perf_schema.file_instances.remove_prefix="/var/lib/mysql/"

                               Remove path prefix in performance_schema.file_summary_by_instance

      --web.listen-address=":9104"

                               Address to listen on for web interface and telemetry.

      --web.telemetry-path="/metrics"

                               Path under which to expose metrics.

      --timeout-offset=0.25    Offset to subtract from timeout in seconds.

      --config.my-cnf="/home/jalright/.my.cnf"

                               Path to .my.cnf file to read MySQL credentials from.

      --collect.mysql.user     Collect data from mysql.user

      --collect.info_schema.tables

                               Collect metrics from information_schema.tables

      --collect.info_schema.innodb_tablespaces

                               Collect metrics from information_schema.innodb_sys_tablespaces

      --collect.info_schema.innodb_metrics

                               Collect metrics from information_schema.innodb_metrics

      --collect.global_status  Collect from SHOW GLOBAL STATUS

      --collect.global_variables

                               Collect from SHOW GLOBAL VARIABLES

      --collect.slave_status   Collect from SHOW SLAVE STATUS

      --collect.info_schema.processlist

                               Collect current thread state counts from the information_schema.processlist

      --collect.perf_schema.tablelocks

                               Collect metrics from performance_schema.table_lock_waits_summary_by_table

      --collect.perf_schema.eventsstatements

                               Collect metrics from performance_schema.events_statements_summary_by_digest

      --collect.perf_schema.eventsstatementssum

                               Collect metrics of grand sums from performance_schema.events_statements_summary_by_digest

      --collect.perf_schema.eventswaits

                               Collect metrics from performance_schema.events_waits_summary_global_by_event_name

      --collect.auto_increment.columns

                               Collect auto_increment columns and max values from information_schema

      --collect.binlog_size    Collect the current size of all registered binlog files

      --collect.perf_schema.tableiowaits

                               Collect metrics from performance_schema.table_io_waits_summary_by_table

      --collect.perf_schema.indexiowaits

                               Collect metrics from performance_schema.table_io_waits_summary_by_index_usage

      --collect.info_schema.userstats

                               If running with userstat=1, set to true to collect user statistics

      --collect.info_schema.clientstats

                               If running with userstat=1, set to true to collect client statistics

      --collect.info_schema.tablestats

                               If running with userstat=1, set to true to collect table statistics

      --collect.info_schema.schemastats

                               If running with userstat=1, set to true to collect schema statistics

      --collect.perf_schema.file_events

                               Collect metrics from performance_schema.file_summary_by_event_name

      --collect.perf_schema.file_instances

                               Collect metrics from performance_schema.file_summary_by_instance

      --collect.perf_schema.replication_group_member_stats

                               Collect metrics from performance_schema.replication_group_member_stats

      --collect.perf_schema.replication_applier_status_by_worker

                               Collect metrics from performance_schema.replication_applier_status_by_worker

      --collect.engine_innodb_status

                               Collect from SHOW ENGINE INNODB STATUS

      --collect.heartbeat      Collect from heartbeat

      --collect.slave_hosts    Scrape information from 'SHOW SLAVE HOSTS'

      --collect.info_schema.innodb_cmp

                               Collect metrics from information_schema.innodb_cmp

      --collect.info_schema.innodb_cmpmem

                               Collect metrics from information_schema.innodb_cmpmem

      --collect.info_schema.query_response_time

                               Collect query response time distribution if query_response_time_stats is ON.

      --collect.engine_tokudb_status

                               Collect from SHOW ENGINE TOKUDB STATUS

      --log.level="info"       Only log messages with the given severity or above. Valid levels: [debug, info, warn, error, fatal]

      --log.format="logger:stderr"

                               Set the log target and format. Example: "logger:syslog?appname=bob&local=7" or "logger:stdout?json=true"

      --version                Show application version.

部署服務

直接注冊成systemd服務。

```bash

#!/bin/bash

VERSION="0.12.1"

wget  -t 100  -c  https://github.com/prometheus/mysqld_exporter/releases/download/v${VERSION}/mysqld_exporter-${VERSION}.linux-amd64.tar.gz

if [ ! -e mysqld_exporter-${VERSION}.linux-amd64.tar.gz ]

then

    echo "安裝包下載失敗"

    exit 1

fi

tar xvfz mysqld_exporter-${VERSION}.linux-amd64.tar.gz -C /opt/

cd /opt

ln -s mysqld_exporter-${VERSION}.linux-amd64  mysqld_exporter

cat > /etc/systemd/system/mysqld_exporter.service <<EOF

[Unit]

Description=mysqld_exporter

After=network.target

[Service]

Type=simple

WorkingDirectory=/opt/mysqld_exporter

ExecStart=/opt/mysqld_exporter/mysqld_exporter --config.my-cnf="/opt/mysqld_exporter/.my.cnf"

LimitNOFILE=65536

PrivateTmp=true

RestartSec=2

StartLimitInterval=0

Restart=always

[Install]

WantedBy=multi-user.target

EOF

?```

systemctl daemon-reload

systemctl enable mysqld_exporter

systemctl start mysqld_exporter

配置prometheus Job

默認端口是9104

- job_name: 'mysqld_exporter'

  # metrics_path defaults to '/metrics'

  # scheme defaults to 'http'.

  static_configs:

  - targets: ['localhost:9104']
